High Density Vertical Carousel Automatic Shelving Designing Rack AS/RS System

1 / 5

High Density Vertical Carousel Automatic Shelving Designing Rack AS/RS System

Send Inquiry

Product Description

Radio Shuttle Racking Solution

Increased volume ratio
Higher warehouse-in/out efficiency than manual forklift
Manual remote control, realizing semi-automatic warehouse in/out
Out-of-stock mode: First in first out/first in last out

Technical Specifications

Pallet size: L1200 X W1000 X H1150; Weight: 1000kg/pallet
Cargo space: 36 rows x 19 columns x 6 levels (Total: 4104 pallets)
Floor area of rack: 47m long X 23m wide x 9m high
Workshop floor area: 60m long x 26m x 11m high

Stacker Crane + Pallet Runner System

Pallet size: L1200 X W1200 X H1000; Weight: 1000kg/pallet
Cargo space: 22 rows x 31 columns x 9 levels (Total: 6138 pallets)
Floor area of rack: 43.5m long X 30m wide x 13m high
Workshop floor area: 58.5m long x 38m wide x 14m high

Multi Shuttle System Solution

Box size: L600 X W400 X H280; Weight: 35kg/box
Cargo space: 29 rows x 19 columns x 15 levels (Total: 16530 boxes)
Floor area of rack: 30m long X 14m wide x 10m high
Workshop floor area: 40m long x 26m wide x 12m high

Four-way Shuttle System Solution

Line side library of smart factory workshop
Frozen/fresh food warehouse
Logistics transition center
Unmanned dark warehouse

Stacker Crane System

Pallet size: L1200 X W1200 X H1200; Weight: 1000kg/pallet
Cargo space: 27 rows x 20 columns x 12 levels (Total: 6480 pallets)
Floor area of rack: 43m long X 45m wide x 19m high
Workshop floor area: 65m long x 55m wide x 20m high

Warehouse Control System (WCS)

The Warehouse Control System (WCS) serves as a bridge between the Warehouse Management System (WMS) and a broad range of material handling equipment such as conveyor systems, automated storage and retrieval systems, carousels, sorters, palletizers and so on.

Acting as a “hub”, the WCS is responsible for keeping everything running smoothly and maximizing the efficiency of material handling systems and subsystems.

Project Cases & Components

Frequently Asked Questions

1. Are you a distributor or a manufacturer?

We are a professional and leading manufacturer for nearly 20 years. We produce and export high-quality pallet racking, multi-shuttle systems, radio shuttle racking, and ASRS. Our annual production capacity is 100,000 tons of rack components and 1,000 units of shuttle cars.

2. What makes your automation solutions unique?

We have more than 40 mechanical, electrical, and software engineers focusing on product innovation and R&D. We maintain our own research teams and cooperate with well-known institutes to enhance technical strength. We also offer independently developed WMS and WCS systems with over 60 national patents.

3. What is the standard manufacturing lead time?

For normal orders, we promise to produce within 20-30 days. As a manufacturer, we can ensure the delivery time according to the formal contract.

4. Do you provide installation and debugging services?

Yes, we have installation teams with rich overseas experience. For radio shuttle cars, we send engineers to the site for debugging and training. For racking systems, we can utilize our own teams or appoint engineers to guide the operation. We have successfully completed projects in Southeast Asia, America, and Europe.

5. What is the Minimum Order Quantity (MOQ)?

Normally, the MOQ is one 20ft container, but larger quantities come with more competitive pricing.

6. What are the accepted payment terms?

We generally accept T/T (Telegraphic Transfer) or L/C (Letter of Credit).
